- Specs: Voltage: 12, Continuous Amps: 100, Surge Amps: 200, Mounting: Curved, 2.22 Duty Cycle: Intermittent, Case Material: Plastic, Contact Material: Copper, Number of Terminals: 3, Includes Hardware SPST (2) 5/16-18 Threaded Terminals (1) 10-32 Threaded Terminal Application: MTE Hydraulic Pump Applications Weight: 0.71 lbs / 0.32 kg
- Compatible with/replacement for OEM Numbers: : Prestolite 15-535, SAZ4201GF
- 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
- 100% New aftermarket Solenoid built to meet OEM specifications
- Replaces OEM Numbers: Arrowhead: PLSAZ4201GF
Verify part fits before purchasing
Cole Hersee Replacement Solenoid is an electromagnetic relay used in a direct current wiring system between a low current capacity switch and a high current load requirement.
In an engine starting system, the ignition switch in the start position may have a rating of 5 amps whilst the starter motor may have a cranking requirement of 200 to 350 amps.
Once energized by the ignition switch, the solenoid coil moves the high current capacity contact to a closed position, thereby energizing the starter motor.
Manufacturer's warranty applies. To ensure tool accuracy and personal safety, do not attempt to repair tools under warranty
